Fogbow Polarisation Enhancement

This series of three images, taken in quick succession, shows the the same section of fogbow without a filter then with a polariser aligned along and across the lower section of bow. This was quite a strong fogbow and showed a bit of colour on the outer edge. No supernumeraries were seen which indicates there was some variation in droplet sizes.

Click here to change angle of polariser

Fogbow polarisation sequence

The view with the polariser along the bow was actually closer to the visual impression than the view recorded without filter.

The orientation of the polariser is shown at the bottom left of each image.

Note: Your browser may need to be set to allow a short script to run. The purpose of the script is to switch the images quickly.

Canon EOS 20D   22nd January 2006
Wiltshire, England
